General Functions of Medical Kiosk

  • 1. Hospital Introduction

    Include: Hospital information, Characteristic Outpatient.

  • 2. Service query

    Include: Drug catalog, Charge details. Support retrieving by the first letter.

  • 3. Self-help medical card register and dispenser

    With identity card, automatically register your medical card, and the terminal machine will dispense the card.

  • 4. Auto appointment

    With your medical card you can select and make appointment with the doctor you want. With receipt printing when the appointment is succeed.

  • 5. Self-register

    Register by kiosk according to hospital processes.With receipt printing function when successfully register.With Payment module ( Cash and Card available)

  • 6. Cash deposit

    With medical card, deposit cash to your outpatient or hospital account.With receipt print function.

  • 7. Bank card deposit

    Pay deposit to outpatient or hospital account. With bank card payment method,through POS machine. receipt print supported.

  • 8. Self service payment

    Paid by your deposited medical card, and print receipt after payment down.

  • 9. Laboratory test report printing

    Self-help prints the reports in kiosk system. Support different sizes of paper.

  • 10. Snapshot and video record function

    Build with specialized kiosk camera, auto recording video and support playback function. Snapshot is to the payment moment.

General Configuration of Medical Kiosk

Product Series Medical Kiosk Terminal
Configurations Description
Industrial Computer Low power consumption, high performance Industrial PC motherboard
Display monitor 15.17.19inch or customized
Touch screen Infrared/SAW type, 15.17.19inch or customized
Social security card reader Customized according to local social security card type.
Medical card reader supports standard magnetic cards, contactless IC card, RF card
Bank card reader Support bank cards including magnetic card and IC card
Barcode scanner Used to scan different kinds of one dimensional code and two dimension code
Encrypted metal keypad 3DES encryption, Security certification of Union pay card terminal, with anti-spy cover
Card printer High resolution thermal Dye-sublimation color printing, high efficiency, easy operation. Support print magnetic card/IC card/RF card.
Receipt printer Thermal printer, 80mm, remind out of paper function. auto cutter.
Laboratory test printer Black and white Laser printer, print A4/A5 paper report.
Banknote recognizer Multi-denomination recognition, four-way banknote insertion, build-in one cash unit with capacity of 1200 bank notes
Fingerprint Reader Use solid optical material, read fingerprint automatically with high recognition
Camera Wide-angle camera、anti-explosion exclusive camera for ATM
POS terminal Motor-driven, push-rod design, the POS can be protected very well avoid damaging
Time setting module Set the time of power on and power off computer part, prolong the service time
UPS power Support PC working in standby model for more than 10 minutes
Kiosk Cabinet Durable cold rolled steel, High & Low temperature resistance, slim and smart design, easy to install, Moisture proof, Antirust, Anti-acid, Anti-dust, Static free
